Collared U-Bolts

In 316 stainless steel with stainless steel nuts under nylon collars. All U-Bolts supplied with 1 plate, 2 nuts and 2 washers in 316 stainless.
*Part No. 0223 has Nyloc nuts and Part No. 0224 has spring washers.
The advantage of the Baseline design for U-Bolts is that they are adjustable from above the deck where there is easy accessibility. The nuts can be run up by hand on the underside of the deck, where confined space often makes it difficult to use a spanner, and then can be tightened from above the deck. If necessary the nuts can be adjusted by up to 3mm, to compensate for any uneveness in the deck. After they are tightened the attractive nylon collars snap over them.

Part No. Product Description Thread H/mm L/mm P/mm Our Price More Details
0223 M8 x 32mm Collared U-Bolt M8 33 23 33 £7.98 Each View more details
0224 M10 x 60mm Collared U-Bolt M10 35 60 35 £12.60 Each View more details
0292 M8 x 64mm Collared U-Bolt M8 40 64 40 £6.66 Each View more details
0293 M10 x 75mm Collared U-Bolt M10 60 80 50 £11.10 Each View more details
0294 M12 x 96mm Collared U-Bolt M12 60 96 60 £25.62 Each View more details
0294A M12 x 55mm Collared U-Bolts M12 55 100 50 £24.00 Each View more details
1011 M10 x 110mm Collared U-Bolt M10 30 110 35 £12.00 Each View more details
